Portman-671 is a portable Raman Spectrometer combined with a semiconductor pumped laser and a standard Raman probe of Oceanhood Taiwan. Not only is it developed for users related to scientific research and industrial process, but it can be used for many fields such as food safety, gem identification, drug analysis…etc.




• Features

• Wide spectral range: 200-3600cm^-1
• High stability; spectral response stability<2% P-P@2hrs
• High resolution (~12cm^-1)

• Specifications

  Models	PR671-D	PR671-T
  Cooling Option	Deep Cooling (-25℃)	Cooling (-5℃)
  Spectra Range(cm-1)	200-3600-1
  Spectral Resolution (cm-1)	<12cm-1 @25μm Slit
  Excitation Wavelength	671±0.8nm，line width≤0.2nm
  Output Power	0-500mW (adjustable)
  Probe Working Distance	7.5 mm
  Dimension	325×220×99 mm
  Weight	~4.4 kg
  Operating temperature	0-40℃
  Operating humidity	5-80%

• Dimensional drawing



• Applications

• Raman detection
• Raw Material Identification
• Medical analysis
• Material analysis
• Optical experimental teaching
• Specialized scientific research




• Typical spectrum
