The OCCS30-KVP1 Five-Axis Adjustment Mount is designed for 30 mm cage systems and features a 0° incidence optical mount with an SM1 mounting thread for integration with compatible optical components.
It provides 1.5 mm precision XY adjustment and five-axis manual adjustment. Each adjustment axis is operated by a control knob, allowing precise positioning and alignment of optical components.
It provides 1.5 mm precision XY adjustment and five-axis manual adjustment. Each adjustment axis is operated by a control knob, allowing precise positioning and alignment of optical components.
-
Features
- Designed for 30 mm cage systems
- 0° incidence optical mount
- SM1 mounting thread
- 1.5 mm XY fine adjustment
- Five-axis manual adjustment
- Knob-operated adjustment mechanism
-
Specifications
| Model | OCCS30-KVP1 |
| Cage system | 30 mm |
| Incidence angle | 0° |
| Mounting interface | SM1 |
| XY Fine Adjustment | 1.5 mm |
| Adjustment | Five-axis manual adjustment with knobs |
-
Dimensional drawing
