Gino is an industrial-grade miniature spectrometer based on an Internet of Things (IoT) architecture. The spectrometer provides 2048 or 4096 spectral channels, with 16-bit A/D conversion, stray light lower than 0.1%, and dark noise lower than 30 RMS (100 ms integration time).
It integrates an embedded computing platform with a 766 MHz main processor, 1 GB DDR memory, and 16 GB Flash storage. The system is preinstalled with the Linux operating system and Uspectral-Gino spectral acquisition software.
The spectrometer is equipped with a Gigabit Ethernet RJ45 interface, HDMI interface, Micro-SD card interface, 15-pin external device interface, and three MMCX interfaces.
The spectrometer can operate independently or function as a slave sensor node. It can operate within an ambient temperature range of 0–40°C, with a spectral temperature drift of approximately 0.1 pixel/°C.
A high-speed configuration is optionally available. The maximum acquisition speed can reach 3000 frames per second, and the A/D quantization sampling and data transmission time is less than 500 µs (2048 channels).
Gino is an industrial-grade micro spectrometer designed for industrial environments and outdoor real-time measurement applications.
-
Features
- 16-bit A/D sampling with 2048 or 4096 channels selectable
- Integration time adjustable from 6 µs to 65 s
- Stray light < 0.1%
- High-resolution optical design
- Operating temperature 0°C – 40°C, wavelength temperature drift < 0.1 pixel/°C
- External trigger < 0.4 µs, jitter < 10 ns, suitable for LIBS and similar measurement scenarios
- Excellent fiber insertion repeatability, deviation ≤ 5%
- High UV-response detector with UV detection capability down to 180 nm
- Low electronic noise with circuit board and detector readout noise ≤ 30 RMS (100 ms integration time)
- Built-in ARM embedded operating system, capable of standalone operation or slave-mode operation
- Gigabit Ethernet RJ45 communication, suitable for long-distance industrial data transmission
- Built-in 16 GB flash storage and support for Micro-SD expansion, enabling onboard measurement, onboard computation, and onboard data storage
- Multiple communication interfaces including serial interfaces, a 15-pin interaction interface, and external trigger interfaces
- Optional high-speed configuration, enabling speeds up to 3000 frames/s, with A/D quantization sampling and data transmission time < 500 µs (2048 channels)
- Provides a secondary development environment based on Debian Linux, supporting QT + C++ embedded software development, and customized software development services
- Supports multiple acquisition modes including single acquisition, continuous acquisition, software trigger, synchronous external trigger, and asynchronous reset external trigger
-
Specification
| Optical Parameters | |
| Optical platform | Czerny-Turner optical path |
| Wavelength range | 200–1100 nm |
| Fiber interface | Key-SMA905 |
| Detector pixels | 2048 pixels |
| Stray light | <0.1% |
| Wavelength temperature drift | ≤0.1 pixel/℃ |
| Functional parameters | |
| A/D sampling | 16 bit |
| Data interface | RJ45、RS232 |
| Expansion interface | 24 PIN |
| Acquisition modes | Single, continuous, software trigger, synchronous external trigger, asynchronous reset external trigger |
| Detector integration time | 6 μs-65 s |
| CCD readout noise | ≤30 RMS |
| CCD dynamic range | 3000:1 |
| Signal-to-Noise Ratio (SNR) | 380:1 |
| Response linearity | ≥99.8% |
| Other parameters | |
| Weight | 370g |
| Weight | 97×80×38 mm |
| Operating temperature | 0℃~40℃ |
| Operating humidity | 20%-85% |
-
Products
| Model | Wavelength | Resolution | ||
| Start | End | Minimum | Typical | |
| Gino-200-1100 | 200 | 1100 | 0.8 | 1.0 |
| Gino-200-800 | 200 | 800 | 0.6 | 0.8 |
| Gino-350-970 | 350 | 950 | 0.6 | 0.8 |
► Minimum resolution corresponds to a 10 µm slit width.
► The specific model requires a defined slit configuration. For example, Gino-200-1100-25 corresponds to a 25 µm slit configuration.
► For high sensitivity requirements, larger slit widths can be selected. Available slit options include 10 µm / 25 µm / 50 µm / 100 µm / 200 µm / 300 µm / 500 µm.
-
Dimensional drawing
-
Typical spectrum
-
Applications
- Detection modules for liquid chromatography / gas chromatography
- Nucleic acid and protein absorbance measurement
- Laser measurement
- Vegetation reflectance / fluorescence measurement
- Fabric / cosmetic reflectance measurement
- Semiconductor plasma etching process monitoring
- Display panel / LED radiation color measurement
- Film thickness measurement / confocal spectroscopy detection modules
- Optical component transmittance testing
- Plasma spectroscopy detection
- Water quality absorption / fluorescence detection
- Raman spectroscopy education
- Full-spectrum UV-VIS spectrophotometry
- LIBS spectroscopy detection
