Available Models: GH10-BNC2SA (AR-Coated Sapphire Window) and GH10-BNC2NW (No Window Type).
-
Specifications
Model Window GH10-BNC2SA (原GM10HSBNC) AR Coated Sapphire Window GH10-BNC2NW No Window
| Type:photodiode | PKG. *BNC | MAT. Ge | |||
| Group A and/0r performance characteristics | |||||
| No. | Symbol | Conditions @23ºc±2ºc | Min. | Max. | Units |
| 1 | RD | @ 850 nm | 0.18 | (Typ.) 0.20 | A/W |
| 2 | @ 1300 nm | 0.65 | (Typ.) 0.70 | A/W | |
| 3 | @ 1550 nm | 0.75 | (Typ.) 0.85 | A/W | |
| 4 | R(SH) | @ VR = 10 mV | 2.0 | (Typ.) 5 | KW |
| 5 | ID | @ VR = 0.5 V | (Typ.) 50 | 70 | mA |
| 6 | CT | @ VR = 1.0 V | 30,000 | pF | |
| 7 | |||||
| 8 | |||||
| 9 | |||||
| 10 | Maximum Ratings | ||||
| 11 | IR | 10 | mA | ||
| 12 | IF | 10 | mA | ||
| 13 | PT | 50 | mW | ||
| 14 | T(stg) | -40 | +125 | ºC | |
| 15 | T(op) | -40 | +85 | ºC | |
| Special requirements | |||||
| GH10-BNC2SA *BNC Housing, AR Coated Sapphire Window Cap. GH10-BNC2NW *BNC Housing, No Window Cap. *Outline Drawing# 30-021 Active Size 10mm²
Max VR 1.0V |
|||||
-
Dimensional drawing
